Router-switch.com Uploaded a Number of Data of Popular Cisco Hardware

Recently, although Cisco is suffering a trust crisis because of the Prism Project in China, for worldwide network users Cisco hardware, especially those popular items (such as Cisco 800 series, Cisco 1900, 2900, Catalyst 2960-S, Cisco 3750-X/3560X switches, Cisco ASA 5500 series and so forth.) is still the top choice to constructing an advanced, safe and stable network.

As a leading Cisco network hardware supplier, router-switch.com this week uploaded a number of data of Cisco routers, Cisco switches and Cisco ASA firewalls to help Cisco users understand the Cisco equipment well. These files contain the diagram to present the detailed functions of every Cisco item, the main bright features, notes for attention, some necessary suggestions related to each popular Cisco product and so on. For example, to explain Cisco 1921/K9 by the detailed image likes this:

1921-K9-L1

LED area description

· SYS: Solid green —normal operation.
          Blinking green —System is booting or is in ROM monitor mode.
          Amber —System error.
          Off —Power is off or system board is faulty.

· ACT: Solid or blinking —any packets are transmitted/received on any WAN/LAN, or when monitoring system activity.

· PoE: Green —PoE is available.
          Amber —Power supply is not supplying PoE power.

1921-k9-file



S (Speed): 1 blink + pause —GE port operating at 10 Mb/s.
                    2 blink + pause —GE port operating at 100 Mb/s.
                    3 blink + pause —GE port operating at 1000 Mb/s.

· L (Link): Green —GE link is established.
                Off —No GE link is established.

Notes for attention to list like this:

1921-k9-L3

Note:

· 1 integrated EHWIC slots for flexible configurations & support of two modules:
         1 double wide HWIC-D or single wide EHWIC/HWIC module;
         or 2 single wide EHWIC/HWIC module .
(Each HWIC Slot offers high data throughput capability with up to 1.6 Gbps aggregate towards the router processor and up to 2 Gbps
aggregate to other module slots over MultiGigabit Fabric (MGF)).

· 1 AUX port (auxiliary port) —RJ-45 connectors for Remote configuration.

· GE 0/0 & 0/1—Two Gigabit Ethernet ports (RJ-45 connectors).

· High-speed USB 2.0 ports enable another mechanism secure token capabilities and storage.

Well, by this way, we can be clear of the structure and functions of Cisco hardware at a glance. If you need to get that information of these hot Cisco products, you can refer to the related pages at router-switch.com. The first batch of Cisco hardware files include CISCO881-K9, CISCO1921/K9, CISCO1921-SEC/K9, CISCO1941/K9, CISCO1941-SEC/K9, CISCO2901/K9, CISCO2911/K9WS-C2960S-24TS-L, WS-C2960S-24TS-S, WS-C2960S-48TS-L, WS-C2960S-48TS-S, WS-C3560X-24T-L, WS-C3560X-24T-S, WS-C3750X-24T-L, WS-C3750X-24T-S, WS-C3750X-48P-S.

More diagrams, note files and necessary advices related to main Cisco equipment will be uploaded soon, more surprises, expectation here!
