The Cisco 550X Series Stackable Managed Switches-Updated

Now Cisco updated its 550X Series Stackable Managed Switches. There are several new Cisco 550X and 350X models available providing Gigabit and Fast Ethernet with 10-Gigabit uplinks and advanced capabilities to accelerate your business growth.

The Cisco 550X Series are the next-generation stackable managed Ethernet switches that provide the advanced capabilities and superior performance you need to support a more demanding network environment at an affordable price.

These switches incorporate fan and power hardware redundancy, increasing overall network availability.

  • The SG550X and SF550X models provide 24 or 48 ports of Gigabit Ethernet and Fast Ethernet connectivity with 10 Gigabit uplinks.
  • The SG550XG models provide 16, 24, or 48 ports of 10 Gigabit Ethernet with both copper and fiber connection options, providing a solid foundation for your current business applications, as well as those you are planning for the future.

At the same time, these switches are easy to deploy and manage, without a large IT staff.

Cisco 550X Series switches are designed to protect your technology investment as your business grows. Unlike switches that claim to be stackable but have elements that are administered and troubleshot separately, the Cisco 550X Series provides true stacking capability, allowing you to configure, manage, and troubleshoot multiple physical switches as a single device and more easily expand your network.

A true stack delivers a unified data and control plane, in addition to a management plane, providing flexibility, scalability, and ease of use because the stack of units operate as a single entity constituting all the ports of the stack members. The switches also protect your technology investment with an enhanced warranty, dedicated technical support, and the ability to upgrade equipment in the future and receive credit for your Cisco 550X Series switch. Overall, the Cisco 550X Series provides the ideal technology foundation for a growing business.

High-Performance 10 Gigabit Ethernet–With 10G copper ports on SG550XG switches, you can easily and cost-effectively enable 10G connections to servers and network storage devices with standard RJ45 Ethernet cable. You can also connect your SG550X access switches to the SG550XG aggregation with 10G SFP+ fiber, building a high-performance backbone to speed up the overall operation of your network.

Advanced Stacking

Some switches claim to support stacking but in practice support only “clustering,” meaning that each switch must still be managed and configured individually. Cisco 550X Series switches provide true stacking capability, allowing you to configure, manage, and troubleshoot all switches in a stack as a single unit, with a single IP address for up to a maximum of 400 Ethernet ports.

A true stack delivers a unified data and control plane, in addition to management plane, providing flexibility, scalability, and ease of use because the stack of units operates as a single entity constituting all the ports of the stack members. This capability can radically reduce complexity in a growing network environment while improving the resiliency and availability of network applications. True stacking also provides other cost savings and administrative benefits through features such as cross-stack QoS, VLANs, LAGs, and port mirroring, which clustered switches cannot support.

Using standard 10G fiber or copper connections, the Cisco 550X Series supports both local and horizontal stacking deployments and the flexibility of ring or chain topology. The switches also have the capability to use link aggregation port as the stacking port, providing even higher stacking bandwidth for demanding applications.

Advanced Layer 3 Traffic Management

The Cisco 550X Series enables a more advanced set of traffic management capabilities to help growing businesses organize their networks more effectively and efficiently. For example, the switches provide static Layer 3 routing, allowing you to segment your network into workgroups and communicate across VLANs without degrading application performance.

With these capabilities, you can boost the efficiency of your network by offloading internal traffic-handling tasks from your router and allowing it to manage primarily external traffic and security.

Additionally, Cisco 550X series provide dynamic Layer 3 routing features. With these capabilities, you can minimize the need to manually configure routing devices and simplify the ongoing operation of the network.

More details of CISCO 550X series you can read the full data sheet here: http://www.cisco.com/c/en/us/products/collateral/switches/550x-series-stackable-managed-switches/datasheet-c78-735874.html

Compare Models: Cisco 550X Series Stackable Managed Switches

The 500X Series provides a solid foundation for the latest technologies. Choose the best model for your needs.

Product
SG550XG-8F8T
SG550XG-24F
SG550XG-24T
SG550X-48T
Product ID
SG550XG-8F8T-K9
SG550XG-24F-K9
SG550XG-24T-K9
SG550XG-48T-K9
General
Device type Switch – 10-Gb – 16 ports – L3 – managed Switch – 10-Gb – 24 ports – L3 – managed Switch – 10-Gb – 24 ports – L3 – managed Switch – 10-Gb – 48 ports – L3 – managed
Enclosure type Rack-mountable – 1U Rack-mountable – 1U Rack-mountable – 1U Rack-mountable – 1U
Ports 8 10-Gb copper + 8 10-Gb SFP+ plus 1 GE OOB Management 22 10-Gb SFP+ slots + 2 combo 10-Gb copper/SFP+ plus 1 GE OOB management 22 10-Gb copper + 2 combo 10G copper/SFP+ plus 1 GE OOB management 46 10-Gb copper + 2 combination 10-Gb copper/SFP+ plus 1 GE OOB management
Performance Switching capacity: 320 Gbps
Forwarding performance (64-byte packet size): 238.08 Mpps
Switching capacity: 480 Gbps
Forwarding performance (64-byte packet size): 357.12 Mpps
Switching capacity: 480 Gbps
Forwarding performance (64-byte packet size): 357.12 Mpps
Switching capacity: 960 Gbps
Forwarding performance (64-byte packet size): 714.24 Mpps
MAC address table size 64,000 entries 64,000 entries 64,000 entries 64,000 entries
Capacity 4000 active VLANs 4000 active VLANs 4000 active VLANs 4000 active VLANs
Routing protocol RIPv2 + static IPv4/IPv6 routing RIPv2 + static IPv4/IPv6 routing RIPv2 + static IPv4/IPv6 routing RIPv2 + static IPv4/IPv6 routing
Remote management protocol SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, SSH, CLI SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, SSH, CLI SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, SSH, CLI SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, SSH, CLI
Compliant standards IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3az IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3az IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3az IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3az
RAM 512 MB 512 MB 512 MB 512 MB
Flash memory 256 MB flash 256 MB flash 256 MB flash 256 MB flash
Status indicators System, Master, Fan, RPS, Stack ID, Link/Speed per port System, Master, Fan, RPS, Stack ID, Link/Speed per port System, Master, Fan, RPS, Stack ID, Link/Speed per port System, Master, Fan, RPS, Stack ID, Link/Speed per port
Expansion and Connectivity
Interfaces 8 x 10Base-T/100Base-TX/1000Base-T/10GBase-T – RJ-45 | 8 10G SFP+ slots | 1 x GE OOB port | 1 x console – RJ45 – management | 1 x RPS port 24 x SFP+ slots | 2 x 10Base-T/100Base-TX/1000Base-T/10GBase-T – RJ-45 (combination) | 1 x GE OOB port | 1 x console – RJ45 – management | 1 x RPS port 24 x 10Base-T/100Base-TX/1000Base-T/10GBase-T – RJ-45 | 2 x SFP+ slots (combination) | 1 x GE OOB port | 1 x console – RJ45 – management | 1 x RPS port 48 x 10Base-T/100Base-TX/1000Base-T/10GBase-T – RJ-45 | 2 x SFP+ slots (combination) | 1 x GE OOB port | 1 x console – RJ45 – management | 1 x RPS port
Power
Power device Power supply – internal Power supply – internal Power supply – internal Power supply – internal
Voltage required AC 120/230 V (50/60 Hz) AC 120/230 V ( 50/60 Hz) AC 120/230 V (50/60 Hz) AC 120/230 V (50/60 Hz)
Miscellaneous
Width 17.3 in 17.3 in 17.3 in 17.3 in
Depth 13.8 in 13.8 in 13.8 in 17.7 in
Height 1.7 in 1.7 in 1.7 in 1.7 in
Weight 11.53 lbs 9.17 lbs 14.07 lbs 16.38 lbs
Cables included 1 x console cable 1 x console cable 1 x console cable 1 x console cable
Compliance standards UL 60950, FCC Part 15 A, CSA 22.2 UL 60950, FCC Part 15 A, CSA 22.2 UL 60950, FCC Part 15 A, CSA 22.2 UL 60950, FCC Part 15 A, CSA 22.2
Environmental Parameters
Minimum operating temperature 32°F 32°F 32°F 32°F
Maximum operating temperature 122°F 122°F 122°F 122°F
Humidity range operating 10 – 90% (non-condensing) 10 – 90% (non-condensing) 10 – 90% (non-condensing) 10 – 90% (non-condensing)
Minimum storage temperature -4°F -4°F -4°F -4°F
Maximum storage temperature 158°F 158°F 158°F 158°F
Humidity range storage 10 – 90% (non-condensing) 10 – 90% (non-condensing) 10 – 90% (non-condensing) 10 – 90% (non-condensing)
Ordering Information—the Cisco 550X Models
Model Name Product Order ID Number Description
10-Gigabit
SF550X-24 SF550X-24-K9 ●  24 x 10/100 ports

●  4 x 10 Gigabit Ethernet (2 x 10GBase-T/SFP+ combo + 2 x SFP+)

SF550X-24P SF550X-24P-K9 ●  24 x 10/100 PoE+ ports with 195W power budget

●  4 x 10 Gigabit Ethernet (2 x 10GBase-T/SFP+ combo + 2 x SFP+)

SF550X-24MP SF550X-24MP-K9 ●  24 x 10/100 PoE+ ports with 382W power budget

●  4 x 10 Gigabit Ethernet (2 x 10GBase-T/SFP+ combo + 2 x SFP+)

SF550X-48 SF550X-48-K9 ●  48 x 10/100 ports

●  4 x 10 Gigabit Ethernet (2 x 10GBase-T/SFP+ combo + 2 x SFP+)

SF550X-48P SF550X-48P-K9 ●  48 x 10/100 PoE+ ports with 382W power budget

●  4 x 10 Gigabit Ethernet (2 x 10GBase-T/SFP+ combo + 2 x SFP+)

SF550X-48MP SF550X-48MP-K9 ●  48 x 10/100 PoE+ ports with 740W power budget

●  4 x 10 Gigabit Ethernet (2 x 10GBase-T/SFP+ combo + 2 x SFP+)

SG550X-24 SG550X-24-K9 ●  24 x 10/100/1000 ports

●  4 x 10 Gigabit Ethernet (2 x 10GBase-T/SFP+ combo + 2 x SFP+)

SG550X-24P SG550X-24P-K9 ●  24 x 10/100/1000 PoE+ ports with 195W power budget

●  4 x 10 Gigabit Ethernet (2 x 10GBase-T/SFP+ combo + 2 x SFP+)

SG550X-24MP SG550X-24MP-K9 ●  24 x 10/100/1000 PoE+ ports with 382W power budget

●  4 x 10 Gigabit Ethernet (2 x 10GBase-T/SFP+ combo + 2 x SFP+)

SG550X-24MPP SG550X-24MPP-K9 ●  24 x 10/100/1000 PoE+ ports with 740W power budget

●  4 x 10 Gigabit Ethernet (2 x 10GBase-T/SFP+ combo + 2 x SFP+)

SG550X-48 SG550X-48-K9 ●  48 x 10/100/1000 ports

●  4 x 10 Gigabit Ethernet (2 x 10GBase-T/SFP+ combo + 2 x SFP+)

SG550X-48P SG550X-48P-K9 ●  48 x 10/100/1000 PoE+ ports with 382W power budget

●  4 x 10 Gigabit Ethernet (2 x 10GBase-T/SFP+ combo + 2 x SFP+)

SG550X-48MP SG550X-48MP-K9 ●  48 x 10/100/1000 PoE+ ports with 740W power budget

●  4 x 10 Gigabit Ethernet (2 x 10GBase-T/SFP+ combo + 2 x SFP+)

SG550XG-8F8T SG550XG-8F8T-K9 ●  8x 10 Gigabit Ethernet 10GBase-T copper port

●  8x 10 Gigabit Ethernet SFP+ (dedicated)

●  1 x Gigabit Ethernet management port

SG550XG-24F SG550XG-24F-K9 ●  24x 10 Gigabit Ethernet SFP+

●  2x 10 Gigabit Ethernet 10Gbase-T copper port (combo with 2 SFP+)

●  1x Gigabit Ethernet management port

SG550XG-24T SG550XG-24T-K9 ●  24x 10 Gigabit Ethernet 10GBase-T copper port

●  2x 10 Gigabit Ethernet SFP+ (combo with 2 copper ports)

●  1x Gigabit Ethernet management port

SG550XG-48T SG550XG-48T-K9 ●  48x 10 Gigabit Ethernet 10GBase-T copper port

●  2x 10 Gigabit Ethernet SFP+ (combo with 2 copper ports)

●  1x Gigabit Ethernet management port

* Each combo port has one 10 Gigabit Ethernet copper port and one 10 Gigabit Ethernet SFP+ slot, with one port active at a time.
