Routing, Switching, and Wi-Fi in Cisco ISR 1000 Series

Just like other fixed ISRs, the new ISR 1000 Series comes in a variety of flavors with interface options to meet just about any need.

  • The Cisco ISR 1000/1100 routers come in two models: an 8-LAN-port option and a 4-LAN-port option.
  • There are multiple LAN, WLAN, WAN, and LTE combinations to choose from, depending on your branch needs.
  • The 1000 Series can be used in ATMs, retail stores, and kiosks, as well as for various other purposes.
  • The Cisco ISR 1000 Series routers are best suited for small and midsize businesses, enterprise branches, and as customer premises equipment in managed services environments.
Cisco ISR 1000 Series Routers-Highlights
  1. Cisco IOS XE Universal Image (IP Base/SEC/AX)
  2. High-performance multicore processors for high-speed WAN connections and multiple services
  3. Dual WAN ports for load balancing and/or business continuity
  4. 4G LTE wireless WAN (select models)
  5. Built-in managed switch (all models)
  6. Optional integrated power supply for distribution of PoE/PoE+
  7. Built-in IEEE 802.11ac Wave 2-compatible wireless access point (wireless models)
  8. Cisco Mobility Express for flexible deployment
Building out the Portfolio

The ISR 1000 Series fleshes out an already extensive portfolio of Enterprise Routing from Cisco. With Multi-CPU IOS-XE systems now from small branch through large aggregation plus cloud and virtual deployments, it’s a common architecture across the network. Add to this the new addition of vEdge appliances and Enterprise NFV and there’s support for exciting emerging architectures.

Cisco ISR 1000 Series-Platform Spec

Cisco IOS Technology Package Licenses
Product SKU Description
SL-1100-4P-SEC Cisco IOS SEC License for Cisco ISR 1111 (4-port Model)
SL-1100-8P-SEC Cisco IOS SEC License for Cisco ISR 1111 (8-port Model)
SL-1100-4P-APP Cisco IOS APP License for Cisco ISR 1111 (4-port Model)
SL-1100-8P-APP Cisco IOS APP License for Cisco ISR 1111 (8-port Model)
Cisco IOS Feature Licenses
Product SKU Description
FL-VPERF-4P-100 Cisco IOS VPER License for Cisco ISR 1111 (4-port Model)
FL-VPERF-8P-200 Cisco IOS VPER License for Cisco ISR 1111 (8-port Model)
FL-1100-4P-HSEC Cisco IOS HSEC License for Cisco ISR 1111 (4-port Model)
FL-1100-8P-HSEC Cisco IOS HSEC License for Cisco ISR 1111 (8-port Model)
Tips: Cisco IOS Software Licensing and Packaging

A single Cisco IOS XE universal image encompassing all functions is delivered with the platform. Advanced features can be enabled simply by activating a software license on the Universal image. The following licenses are available:

  • IP Base: Available as the default.
  • Security (SEC): Includes features for securing network infrastructure.
  • Application Experience (APP): Includes data and application performance features.
  • Performance (VPER): Provides additional IPsec performance 100 Mbps for ISR 1100-4P and 200 Mbps for ISR 1100-8P.
  • High Performance Security (HSEC): Provides High IPsec maximum performance security.
