5 IT Solutions for Business: Cisco UC Solution, Cisco & Aruba Wireless Solutions and HPE Server Solutions

Flash Sale, Cisco, Huawei, Ruckus and more

Hello, guys! Router-switch.com is celebrating the 19th anniversary. To help every customer choose the right products, we also provide 5 trending business solutions, including Cisco UC Solution, Cisco Wireless Solution, Aruba Wireless Solutions and HPE DL360 & DL380 Server Solutions.

Let’s explore.

  1. Cisco UC Solution

Cisco Unified Communications series provides us hot IP phones series, the 7800 and 8800. How to build a useful unified communication system for business, here is the solution:

cisco-uc-solution-architecture

We need to deploy L3 core switch and L2 PoE switch. Of course, UC router and firewall are needed. Because this is a solution of Cisco products, so we can choose below models to build this system:

Category Model Description
UC Router Options ISR4321-V/K9 50Mbps-100Mbps system throughput, 2 WAN/LAN ports, 1 SFP port, multi-Core CPU,2 NIM, Voice Bundle, WAAS, Intelligent WAN, OnePK, AVC
ISR4331-V/K9 100Mbps-300Mbps system throughput, 3 WAN/LAN ports, 2 SFP ports, multi-Core CPU,1 service module slots, Security, Voice, WAAS, Intelligrnt WAN, OnePK, AVC
Firewall Options FG-30E Fortinet FG-30E, 5 x GE RJ45 ports (Including 1 x WAN port, 4 x Switch ports), Max managed FortiAPs (Total / Tunnel) 2 / 2
FG-60E Fortinet FG-60E, 10 x GE RJ45 ports (including 7 x Internal Ports, 2 x WAN Ports, 1 x DMZ Port). Max managed FortiAPs (Total / Tunnel) 30 / 10
FG-100E Fortinet FG-100E, 20 x GE RJ45 ports (including 2 x WAN ports, 1 x DMZ port, 1 x Mgmt port, 2 x HA ports, 14 x switch ports), 2 x Shared Media pairs (Including 2 x GE RJ45 ports, 2 x SFP slots). Max managed FortiAPs (Total / Tunnel) 64 / 32
FG-100F Fortigate 100F FG-100F, 22x GE RJ45 ports (including 2x WAN ports, 1x DMZ port, 1x Mgmt port, 2x HA ports, 16x switch ports with 4 SFP port shared media), 4 SFP ports, 2x 10 GE SFP+ FortiLinks, dual power supplies redundancy. Max managed FortiAPs (Total / Tunnel) 64 / 32. Need to buy with License. Fortinet NGFW Fortigate 100F series.
FG-200E Fortinet FG-200E, 18 x GE RJ45 (including 2 x WAN ports, 1 x MGMT port, 1 X HA port, 14 x switch ports), 4 x GE SFP slots. SPU NP6Lite and CP9 hardware accelerated.
L3 CORE Switch Options C9300-24T-A Catalyst 9300 24-port data only, Network Advantage
C9300-48T-A Catalyst 9300 48-port data only, Network Advantage
L2 POE Switch Options C9200L-24P-4G-E Catalyst 9200L 24-port PoE+ 4x1G uplink Switch, Network Essentials
C9200L-24P-4X-E Catalyst 9200L 24-port PoE+ 4x10G uplink Switch, Network Essentials
IP Phone Options CP-7811-K9 Cisco IP Phone 7811
CP-8811-K9 Cisco IP Phone CP-8811-K9, widescreen grayscale display, High-quality Voice Communication, easy to use, cisco EnergyWise, cost-effective
CP-7975G Cisco Unified IP Phone 7975, Gig Ethernet, Color Cisco 7900 Unified IP Phone
  1. Cisco Wireless Solution

Now the WiFi 6 access points become more popular, Cisco also provides us its Wifi 6 products, such as Catalyst 9100 aps, etc. However, as the price of Catalyst 9100 is a little high, so we still recommend customer to choose WiFi 5 aps, such as AP2800, AP1800, etc.

Here is the solution:

cisco-wifi-solution-architecture

To lower the cost, here we recommend Fortinet firewall to build the system:

Category Model Description
Router Options ISR4321-V/K9 50Mbps-100Mbps system throughput, 2 WAN/LAN ports, 1 SFP port, multi-Core CPU,2 NIM, Voice Bundle, WAAS, Intelligent WAN, OnePK, AVC
ISR4331-V/K9 100Mbps-300Mbps system throughput, 3 WAN/LAN ports, 2 SFP ports, multi-Core CPU,1 service module slots, Security, Voice, WAAS, Intelligrnt WAN, OnePK, AVC
ISR4221/K9 35Mbps-75Mbps system throughput, 2 WAN/LAN ports, 1 SFP port, multi-Core CPU,2 NIM
Firewall Options FG-30E Fortinet FG-30E, 5 x GE RJ45 ports (Including 1 x WAN port, 4 x Switch ports), Max managed FortiAPs (Total / Tunnel) 2 / 2
FG-60E Fortinet FG-60E, 10 x GE RJ45 ports (including 7 x Internal Ports, 2 x WAN Ports, 1 x DMZ Port). Max managed FortiAPs (Total / Tunnel) 30 / 10
FG-100E Fortinet FG-100E, 20 x GE RJ45 ports (including 2 x WAN ports, 1 x DMZ port, 1 x Mgmt port, 2 x HA ports, 14 x switch ports), 2 x Shared Media pairs (Including 2 x GE RJ45 ports, 2 x SFP slots). Max managed FortiAPs (Total / Tunnel) 64 / 32
FG-100F Fortigate 100F FG-100F, 22x GE RJ45 ports (including 2x WAN ports, 1x DMZ port, 1x Mgmt port, 2x HA ports, 16x switch ports with 4 SFP port shared media), 4 SFP ports, 2x 10 GE SFP+ FortiLinks, dual power supplies redundancy. Max managed FortiAPs (Total / Tunnel) 64 / 32. Need to buy with License. Fortinet NGFW Fortigate 100F series.
FG-200E Fortinet FG-200E, 18 x GE RJ45 (including 2 x WAN ports, 1 x MGMT port, 1 X HA port, 14 x switch ports), 4 x GE SFP slots. SPU NP6Lite and CP9 hardware accelerated.
WLC Options AIR-CT3504-K9 Cisco 3504 Wireless Controller
C9800-L-C-K9 Cisco Catalyst 9800-L (Copper Uplink) Wireless Controller
L3 Core Switch Options C9300-24T-A Catalyst 9300 24-port data only, Network Advantage
C9300-48T-A Catalyst 9300 48-port data only, Network Advantage
L2 POE Switch Options C9200L-24P-4G-E Catalyst 9200L 24-port PoE+ 4x1G uplink Switch, Network Essentials
C9200L-24P-4X-E Catalyst 9200L 24-port PoE+ 4x10G uplink Switch, Network Essentials
C9200L-48P-4G-E Catalyst 9200L48-port PoE+ 4x1G uplink Switch, Network Essentials
C9200L-48P-4X-E Catalyst 9200L 48-port PoE+ 4x10G uplink Switch, Network Essentials
Wireless APs Options AIR-AP2802I-E-K9 802.11ac Wave 2 AP w/CleanAir, 4×4:3, Internal Antenna, 2xGbE E Regulatory Domain
AIR-AP1815I-E-K9 Cisco Aironet 1815i Series, Reg Domain E
AIR-AP2802I-H-K9 Cisco 2800 Access Point AIR-AP2802I-H-K9 Dual-band, controller-based 802.11a/g/n/ac Wave 2 standard Intdoor AP, internal-Ant, AC-power, Reg. Domain-H
AIR-AP1832I-H-K9 Cisco AIR-AP1832I-H-K9, 802.11a/g/n/ac Wave 2, Controller based, 3 x 3 MU-MIMO, 1.733Gbps thoughput, Dual-band
  1. Aruba Wireless Solution

Recently, Aruba wireless products become hotter than before. Let’s see how to use Aruba APs to build a wireless network:

aruba-wifi-solution-architecture

The products options include Cisco networking products and Aruba aps:

Category Model Description
Router Options ISR4321-V/K9 50Mbps-100Mbps system throughput, 2 WAN/LAN ports, 1 SFP port, multi-Core CPU,2 NIM, Voice Bundle, WAAS, Intelligent WAN, OnePK, AVC
ISR4331-V/K9 100Mbps-300Mbps system throughput, 3 WAN/LAN ports, 2 SFP ports, multi-Core CPU,1 service module slots, Security, Voice, WAAS, Intelligrnt WAN, OnePK, AVC
ISR4221/K9 35Mbps-75Mbps system throughput, 2 WAN/LAN ports, 1 SFP port, multi-Core CPU,2 NIM
Firewall Options FG-30E Fortinet FG-30E, 5 x GE RJ45 ports (Including 1 x WAN port, 4 x Switch ports), Max managed FortiAPs (Total / Tunnel) 2 / 2
FG-60E Fortinet FG-60E, 10 x GE RJ45 ports (including 7 x Internal Ports, 2 x WAN Ports, 1 x DMZ Port). Max managed FortiAPs (Total / Tunnel) 30 / 10
FG-100E Fortinet FG-100E, 20 x GE RJ45 ports (including 2 x WAN ports, 1 x DMZ port, 1 x Mgmt port, 2 x HA ports, 14 x switch ports), 2 x Shared Media pairs (Including 2 x GE RJ45 ports, 2 x SFP slots). Max managed FortiAPs (Total / Tunnel) 64 / 32
FG-100F Fortigate 100F FG-100F, 22x GE RJ45 ports (including 2x WAN ports, 1x DMZ port, 1x Mgmt port, 2x HA ports, 16x switch ports with 4 SFP port shared media), 4 SFP ports, 2x 10 GE SFP+ FortiLinks, dual power supplies redundancy. Max managed FortiAPs (Total / Tunnel) 64 / 32. Need to buy with License. Fortinet NGFW Fortigate 100F series.
FG-200E Fortinet FG-200E, 18 x GE RJ45 (including 2 x WAN ports, 1 x MGMT port, 1 X HA port, 14 x switch ports), 4 x GE SFP slots. SPU NP6Lite and CP9 hardware accelerated.
L3 Core Switch Options C9300-24T-A Catalyst 9300 24-port data only, Network Advantage
C9300-48T-A Catalyst 9300 48-port data only, Network Advantage
L2 POE Switch Options C9200L-24P-4G-E Catalyst 9200L 24-port PoE+ 4x1G uplink Switch, Network Essentials
C9200L-24P-4X-E Catalyst 9200L 24-port PoE+ 4x10G uplink Switch, Network Essentials
C9200L-48P-4G-E Catalyst 9200L48-port PoE+ 4x1G uplink Switch, Network Essentials
C9200L-48P-4X-E Catalyst 9200L 48-port PoE+ 4x10G uplink Switch, Network Essentials
Wireless APs Options JX945A Aruba IAP-305 (RW) Instant 2x/3x 11ac AP
JW797A Aruba AP-315 802.11n/ac 2×2:2/4×4:4 MU-MIMO Dual Radio Integrated Antenna AP
  1. HPE Server Solutions: DL360

To configure a server, we need to select CPU, hard disk, memory, PCI-E card, NIC, power supply and NIC:

server-basic-components-structure

Here is a deployment of server and storage:

solution-diagram

As HPE is the world top server player, its ProLiant series provides

(1) Optimization

– Workload Matching

– Workload Performance Advisor

(2) Secure

– HPE Silicon Root of Trust

– HPE Secure Compute Lifecycle

– HPE Support of Commercial National Security Algorithm

– HPE Automated Recovery

(3) Automation

– HPE InfoSight for Servers

– Increased manageability delivered through HPE Integrated Lights-Out 5

– All-in-one converged management option with HPE OneView

In this ProLiant product family, HPE ProLiant DL360 Gen10 Server delivers security, agility and flexibility without compromise. It supports the Intel® Xeon® Scalable processor with up to a 71% performance gain and 27% increase in cores, along with 2666 MT/s HPE DDR4 SmartMemory supporting up to 3.0 TB2 with an increase in performance of up to 66%

Here is the DL360 CTO configuration:

Category Model Qty
Basic Chassis HPE DL360 8 SFF CTO P19766-B21

HPE DL360 8 SFF CTO Configured Server P19766-B21

1
CPU P02595-L21

HPE DL360 Gen10 Intel Xeon-Gold 5220 (2.2GHz/18-core/125W) FIO Processor Kit

1
Memory P00922-B21 HPE 16GB Dual Rank x8 DDR4-2933

HPE 16GB (1x16GB) Dual Rank x8 DDR4-2933 CAS-21-21-21 Registered Smart Memory Kit

1
HDD Drive 872481-B21 HPE 1.8TB SAS 10K SFF SC 512E DS HDD

HPE 1.8TB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty 512e Digitally Signed Firmware HDD

1
Smart Array 804331-B21

HPE Smart Array P408i-a SR Gen10 Ctrlr

1
Smart Storage Battery P01366-B21

HPE 96W Smart Storage Battery 145mm Cbl

1
Network Card 629135-B22

HPE Ethernet 1Gb 4-port 331FLR Adapter:ProLiant Accy – NICs/Networking

1
Power supply 865414-B21 HPE 800W Flex Slot Platinum

865414-B21, HPE 800W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit

1
Rail kit 874543-B21

HPE 1U Gen10 SFF Easy Install Rail Kit

1
  1. HPE Server Solutions: DL380

In this part, as DL380 belongs to the HPE ProLiant series, so we can omit the above introduction.

HPE DL380 Gen10 platform is 2U height and supports two Intel Xeon processors, two power supplies. This platform accommodates a number of different chassis configurations with remarkable storage flexibility to support diversified workloads including, containers, virtualization, cloud, and big data applications.

Here is the DL380 CTO configuration:

Category Model Qty
Basic Chassis HPE DL380 Gen10 8SFF CTO P19720-B21

HPE DL380 Gen10 8SFF NC CTO Svr

1
CPU P02502-L21

HPE DL380 Gen10 Intel Xeon-Gold 6230 (2.1GHz/20-core/125W) FIO Processor Kit

1
Memory P00924-B21 HPE 32GB Dual Rank x4 DDR4-2933

HPE 32GB (1x32GB) Dual Rank x4 DDR4-2933 CAS-21-21-21 Registered Smart Memory Kit, P00924-B21

1
HDD Drive HPE 960GB SAS RI SFF SC SSD P19903-B21

HPE 960GB SAS RI SFF SC SSD P19903-B21

1
Smart Array 804331-B21

HPE Smart Array P408i-a SR Gen10 Ctrlr

1
Smart Storage Battery P01366-B21

HPE 96W Smart Storage Battery 145mm Cbl

1
Network Card 629135-B22

HPE Ethernet 1Gb 4-port 331FLR Adapter:ProLiant Accy – NICs/Networking

1
Power supply 865414-B21 HPE 800W Flex Slot Platinum

865414-B21, HPE 800W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit

1
Rail kit 733660-B21

HPE 2U Small Form Factor Easy Install Rail Kit

1

If you have other needs of IT solutions, welcome to contact us: sales@router-switch.com.
